플랜트산업펌프
DNSV Series
Horizontal, Single Stage, Volute Casing Centrifugal Pumps, according to the Korean Standard(KS B 7501)
표준형식
적용 분야 및 용도
- Water treating industries
- Chemical industries
- Petroleum refineries
- All other sorts of industries
- Sea Water
특징
- Various Uses
- Back Pull-Out type design for easy maintenance and repair
- Maximum Efficiency
- Solid Structure
- Best Compatibility
- Low net positive suction head required(NPSHr)
표준사양
| 토출량 | 0.05~37㎥/min |
| 전양정 | ~130m |
| 온도 | -20°C ~ 120°C |
| 회전수 | 1180rpm, 1750rpm, 3500rpm(60Hz) |
| 회전방향 | C.W(Viewed from drive end) |
| 패킹부 | Grand Packing, Mechanical Seal |
| 플랜지규격 | Ratings : KS 10Kgf/㎠ , ANSI 150lb Facing: FF, RF Location : End Suction, Top Discharge |
| 재질 | GC200, SC420, SSC13·14·16(ASTM CF-8, CF-8M, CF-3M) Hastelloy-B·C, Titanium, Carpenter20, Alloy-20 |
| Bearing Lubricant | Oil bath or Grease Type |
SELECTION VIEW
MODULAR INTERCHANGEABILITY
SELECTION CHART
사양
사양
